Object Detection with YOLO

Real-time object detection, tracking, and anomaly detection

Object detection goes beyond image classification: the model must locate each object with a bounding box and classify it simultaneously. YOLO (You Only Look Once) is the dominant real-time detection framework, processing a full image in a single forward pass.

Detection vs. classification

Task	Output	Example
Classification	Single class label	”cat”
Detection	Bounding boxes + class labels	[(x,y,w,h, "cat"), (x,y,w,h, "dog")]
Segmentation	Pixel-wise mask	Per-pixel class assignment

YOLO architecture overview

YOLO divides the input image into an $S \times S$ grid. Each grid cell predicts $B$ bounding boxes and $C$ class probabilities simultaneously.

Bounding box prediction

Each bounding box prediction consists of 5 values:

$[x, y, w, h, \text{confidence}]$

• $(x, y)$: center of the box relative to the grid cell.
• $(w, h)$: width and height relative to the full image.
• Confidence: $\Pr(\text{Object}) \times \text{IoU}^{\text{truth}}_{\text{pred}}$

Anchor boxes

Modern YOLO versions use anchor boxes — predefined aspect ratios learned from the training data via k-means clustering. Each anchor handles objects of a specific size and shape.

Multi-scale detection

YOLOv5 and later versions detect objects at three scales (large, medium, small feature map strides), allowing the network to handle objects of very different sizes in the same image.

Running YOLO inference

# Using Ultralytics YOLOv8
from ultralytics import YOLO

# Load a pretrained model
model = YOLO('yolov8n.pt')  # nano variant for speed

# Run inference on an image
results = model('image.jpg', conf=0.25, iou=0.45)

# Inspect results
for result in results:
    boxes = result.boxes          # bounding box tensors
    for box in boxes:
        x1, y1, x2, y2 = box.xyxy[0]
        conf  = box.conf[0].item()
        cls   = int(box.cls[0].item())
        label = model.names[cls]
        print(f"{label}: {conf:.2f}  [{x1:.0f},{y1:.0f},{x2:.0f},{y2:.0f}]")

Object tracking

YOLO can be combined with tracking algorithms (DeepSORT, ByteTrack) to assign persistent IDs across video frames:

# Tracking with YOLOv8
results = model.track('video.mp4', persist=True, tracker='bytetrack.yaml')

for result in results:
    if result.boxes.id is not None:
        track_ids = result.boxes.id.int().cpu().tolist()
        boxes     = result.boxes.xyxy.cpu().tolist()

Evaluation metrics

Intersection over Union (IoU)

$\text{IoU} = \frac{|\text{Prediction} \cap \text{Ground Truth}|}{|\text{Prediction} \cup \text{Ground Truth}|}$

A prediction is considered correct when $\text{IoU} \geq 0.5$ (PASCAL VOC) or averaged over $[0.5, 0.95]$ (COCO).

Precision and Recall

$\text{Precision} = \frac{\text{TP}}{\text{TP} + \text{FP}} \qquad \text{Recall} = \frac{\text{TP}}{\text{TP} + \text{FN}}$

Mean Average Precision (mAP)

mAP is the primary benchmark for detection models. It averages the area under the precision-recall curve (AP) across all object categories:

$\text{mAP} = \frac{1}{C} \sum_{c=1}^{C} \text{AP}_c$

Anomaly detection

Anomaly detection in computer vision identifies out-of-distribution samples — defective products, unusual events, or unseen object types.

Common approaches:

• Reconstruction-based: autoencoders trained on normal data; high reconstruction error signals anomalies.
• Feature distribution: fit a Gaussian on embeddings from normal samples; Mahalanobis distance detects outliers.
• One-class classification: models like PatchCore or PaDiM trained exclusively on normal images.

When to use anomaly detection vs. supervised detection

Use anomaly detection when:

• Defect types are unknown or highly variable.
• You only have access to “normal” samples during training.
• The defect rate is extremely low (few labeled examples).

Use supervised YOLO-style detection when:

• Defect categories are well-defined and labeled data is available.
• You need bounding box localization with class labels.

CLIP for zero-shot detection

CLIP (Contrastive Language-Image Pretraining) learns a joint embedding space for images and text. This enables zero-shot detection: describe an object in natural language and find it without any labeled images.

import torch
import clip
from PIL import Image

device = "cuda" if torch.cuda.is_available() else "cpu"
model, preprocess = clip.load("ViT-B/32", device=device)

image = preprocess(Image.open("image.jpg")).unsqueeze(0).to(device)
texts = clip.tokenize(["a person wearing a mask",
                       "a person without a mask"]).to(device)

with torch.no_grad():
    image_features = model.encode_image(image)
    text_features  = model.encode_text(texts)
    logits, _      = model(image, texts)
    probs          = logits.softmax(dim=-1).cpu().numpy()

print(f"Mask: {probs[0][0]:.2%}  No mask: {probs[0][1]:.2%}")

Resources

YOLO Example Notebook

Complete YOLO object detection example from the course.

Anomaly Detection Examples

Colab notebook with anomaly detection techniques applied to visual inspection.

CLIP Notebook

CLIP zero-shot classification and retrieval examples.

Video: YOLO Lecture (2021)

Recorded lecture on YOLO object detection and tracking.

Exercise E06 covers YOLO-based mask detection. The full exercise and solution notebooks are distributed via the course Canvas page. The course repository contains related data files and project templates.
